Vacumm suction cup VAS-30-1/8-PUR-B (1396090) - Festo
₹531.90 ₹627.64
In stock
| Product Name | Vacumm suction cup VAS-30-1/8-PUR-B (1396090) - Festo |
|---|---|
| Weight | 12.000000 |
| Brand | Festo |
| Test Certificate | No |
| COUNTRY OF MANUFACTURE | India |
| Vaccume_Connection | G1/8 |
| Suction_Cup_Diameter | 30 mm |
| Suction_Cup_Volume | 1.29 cm³ |
| HSN Code | 84129090 |
| Freight | To pay by Customer, extra at actuals. Godown Delivery |
| Category | Pneumatics, Vacuum Gripper |
| Product Code | DT-0239 |
In Stock ( 198 Units )
Vacumm suction cup VAS-30-1/8-PUR-B (1396090) - Festo
|
Suction cup diameter
|
30 mm |
|
Effective suction cup diameter
|
24.8 mm |
|
Suction cup shape
|
Round, flat |
|
Suction cup material
|
PUR |
Techncial Data
| Suction cup height compensation | 1.9 mm |
| Nominal width | 3 mm |
| Suction cup diameter | 30 mm |
| Suction cup volume | 1.29 cm³ |
| Effective suction cup diameter | 24.8 mm |
| Connection position | Top |
|
Mounting position |
Any |
| Symbol | 00991485 |
| Suction cup shape | Round, flat |
| Operating pressure | -0.095 MPa ... 0 MPa |
|
Operating pressure |
-0.95 bar ... 0 bar |
| Operating pressure | -13.775 psi ... 0 psi |
|
Nominal operating pressure |
-0.07 MPa |
|
Nominal operating pressure |
-0.7 bar |
|
Nominal operating pressure |
-10.15 psi |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
|
Corrosion resistance class (CRC) |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-A1-L |
| Ambient temperature | -20 °C ... 60 °C |
| Holding force at nominal operating pressure | 34 N |
|
Product weight |
12 g |
| Type of mounting | Via vacuum connection |
| Vacuum connection | G1/8 |
| Color | Blue |
|
Shore hardness |
60 +/- 5 |
| Material of screwed plug | Brass |
| Note on materials | RoHS-compliant |
| Suction cup material | PUR |
| Part No | 1396090 |
