Cast Steel Sleeve Packed Water Level Gauge, Flanged, IBR, CS-6 - SANT Valves
₹20,738.00 ₹24,470.84
In stock
| Product Name | Cast Steel Sleeve Packed Water Level Gauge, Flanged, IBR, CS-6 - SANT Valves |
|---|---|
| Weight | 1.000000 |
| Valve Size | 20mm |
| Brand | Sant Valves |
| Test Certificate | No |
| Model | CS-6 |
| Metal | Cast Steel |
| IBR Approved | Yes |
| Body Matrial | CCS (ASTM A216 Gr.WCB) |
| COUNTRY OF MANUFACTURE | India |
| HSN Code | 84818030 |
| Warranty | 6 Months |
| Category | Industrial Valves, Level Gauges, Water Level Gauge , Flanged Ends |
| Product Code | DEV-0107 |
In Stock ( 500 Units )
Product : ‘SANT’ Cast Steel Sleeve Packed Water Level Gauge
Body Material cum Standard : CCS (ASTM A216 Gr.WCB)
Description : With automatic shut off device in the water arm Right Hand / Left Hand Type
Trim : Stem SS AISI-410, Ball AISI-304
End Details : Flanges as per BS 10 Table J FF Undrilled
Testing & Certification
Body Test Pressure : 700 Psig Hyd.
Seat Test Pressure : 350 Psig Hyd.
Working Pressure : Max. BOP 350 Psig. (24.61Kg/cm²)
Maximum Working Temperature: 400ºC
Test Certificate in Form lll-C as per IBR is furnished with every supply.
| Components | Materials | Specifications |
|---|---|---|
| Body, Bonnet & Back Nuts | Cast Steel | ASTM A216 Gr.WCB |
| Sleeve | Moulded Asbestos | — |
| Spindle & Cover Nuts | Stainless Steel | AISI-410 |
| Handles | S.G. Iron | — |
| Name Plate | Brass Sheet | — |
| Rubber Cones | Rubber | — |
| Fasteners | Mild Steel | BS:916 |
